Before You Begin

IMPORTANT WARNINGS

Improper installation will create an electrical hazard which could result in death or serious injury to users, installers, or others due to electric shock.

Short-term inhalation of high concentrations of ozone and long term inhalation of low concentrations of ozone can cause serious harmful physiological effects. DO NOT inhale ozone gas produced by this device.

Do not store or use gasoline, chemicals or other flammable liquids or vapors near this or any other appliance.

Specifications & Requirements

Power Requirements:  240V, 60 Hz, 1Ø, 0.6 Amp

Location Requirements:  Mounting: Designed to be floor mounted in a clean, protected area.

Ambient Temperature:  30°F – 120°F (0°C – 50°C)

Max Flow Rate (for NSF 50 compliance):  189 LPM (50 GPM)

Pool Preparation

The pool must be as clean as possible prior to AOP 50 installation.

Backwash or clean filters one day before starting the ozone generator. Run pool filtration continuously for 24 hours prior to starting the ozone system.

Superchlorinate pool water using a chlorine-based shock treatment so the water has a sustained 1-3 ppm free chlorine level.

Test pool chemistry and adjust pH between 7.4 and 7.6. Adjust total alkalinity between 80 and 120 ppm.

Finding a Location

The DEL AOP 50 must be installed in an outdoor location (out of direct sunlight), or indoors in a forced air ventilated room.

Verify that AOP 50 is inaccessible to anyone in the pool and at least 5 feet (1.5 meters) from wall of pool.

Keep out of reach of sprinklers or drainage spouts.
