• VGB Pool Drains & Suctions

    Safety Certified Standard and Unblockable Drains

PREMIER SELECTION

Our selection of pool drains and suctions is designed to make your choices simple. You don’t need a confusing array of styles– you need the right drain for the job.

KEY FEATURES

SEVEN YEAR LIFE

Remember to check your drains. To comply with the ANSI/APSP - 16 2011 standard, all CMP covers and screws need to be replaced every SEVEN YEARS from date of installation.

CERTIFIED SAFETY

All CMP drains and suctions are IAPMO or UL Listed VGB Suctions and compliant to ANSI/APSP - 16 2011 & CPSC Requirements

COLOR MATCH INSTALLATION

CMP drains and suctions covers are available in seven different colors. Color covers hide the sump, leaving no unsightly white ring on the pool surface.

THE DRAINS YOU WANT, THE SAFETY YOU NEED

All CMP main drains are listed and tested in strict accordance to the requirements of ANSI/APSP - 16 2011, the current standard of reference for the Virginia Graeme Baker Act, and compliant to the latest Consumer Product Safety Commission (CPSC) requirements

UNBLOCKABLE DRAINS

Set the standard for drain and suction safety.

With the convenience of a single drain installation, pool owners can rest easy knowing the drain cannot be blocked to create a suction hazard. All CMP Unblockable Drains are available in flush, slim designs and multiple colors that blend into the poolscape. They also feature high flow designs to help give you the best water quality and system performance.

PRODUCT SPECIFICATIONS

1-7/8″ Cover Width

46.27in² Open Area

Two 2″ Socket x 2.5″ Spigot Ports

216 GPM at 1.5 FPS

PRODUCT SPECIFICATIONS

Floor or Wall Installation

38.79in2  Open Area

Three 2″ Socket × 2.5″ Spigot Ports

181 GPM at 1.5 FPS

FEATURED CONTENT

Check out the VGB Drain Safety Checklist

GALAXY & NOVA DRAINS

Traditional style main drains designed for multiple drain use

CERTIFIED POOL DRAINS FOR GUNITE AND VINYL

Galaxy main drains include our widest selection of install options

  • Gunite and vinyl pool options
  • Standard or deep body sump
  • 8″ and 7-3/4″ size options
  • Complete pool fitting kit selection

PRODUCT SPECIFICATIONS

Floor or Wall Installation

84 GPM (Wall)

95 GPM (Floor)

2″ FIP  or 2″ Socket

13.2in² Open Area

61 GPM at 1.5 FPS

HIGH FLOW MAIN DRAINS FOR GUNITE POOLS

Nova main drains include premier choices for gunite pool installations.

  • Bottom and side port options
  • Available in large outlet deep body styles
  • Extension collar styles for perfect adjustment to plaster height

PRODUCT SPECIFICATIONS

Floor or Wall Installation

1.5″ = 140 GPM (Floor)

118 GPM (Wall)

2″ =  150 GPM (Floor) / 118 GPM (Wall)

14.57 in2 Open Area

68 GPM at 1.5 FPS
